Star LED Dance Floor
Reflected depth and points of light create a 3D star effect. Choose 50 × 50 × 7 cm or 60 × 60 × 7 cm panels, with 10 mm tempered glass and 96 built-in effects. The range lists DMX, controller, remote and voice control options.
- 3D starry mirror effect
- 96 built-in effects
- Magnetic setup options
Share your floor dimensions and destination. We’ll help plan the panel layout and accessory list.
A closer look
at your floor.
Let every moment sparkle. Compare the panel specification and choose the control and connection options that fit your setup.
Confirm the complete system, electrical requirements and included accessories before ordering. Panel protection ratings do not define the weather suitability of the full installation.
| Panel size | 500 × 500 × 70 mm / 600 × 600 × 70 mmLength × width × total panel height; edge ramps excluded. |
|---|---|
| Built-in effects | 96 built-in effectsOriginal-site Star model, distinct from supplier TP-878 programs. |
| 50 cm panel weight | 11 kg per 50 cm panelFAQ does not separate wired, battery or surface-finish configurations. |
| 60 cm panel weight | 14 kg per 60 cm panelFAQ does not separate wired, battery or surface-finish configurations. |
| Connection options | Wired / magnetic / rechargeable magneticAlternative configurations; not one interchangeable hardware specification. |
| Control options | DMX / remote / controllerShort launch list. Original page also says Voice without defining that mode. |
| LED type | SMD 5050 RGB LEDsLED component type; no high-resolution video pixel-pitch claim. |
| Colours | 16.7 million colours |
| Refresh rate | 2,000 HzPublished feature; camera-shutter test conditions not stated. |
| Tempered glass | 10 mmGlass surface thickness; not total panel height. |
| Panel protection | IP67; use away from outdoor rainOriginal page lists panel IP67. Power supplies and connections require their described protection; the FAQ on this product excludes outdoor rain. |
| Packing options | Flight case / CartonPacking style only; final case count, dimensions and gross weight depend on the quoted configuration. |
| LED-source life | 10+ years (LED source)Feature discusses LED-source durability; not a warranty term. |
Request the documentation matched to your selected product configuration and destination market.
Make every part work together.
Panels & layout
Choose the effect and panel format. Share your usable floor length and width.
Power & control
Match power supplies and control options to the selected floor and your event workflow.
Edges & accessories
Plan perimeter edges, connections and recommended spares for your configuration.
Transport & packing
Specify flight cases or cartons to suit frequent event moves or a fixed installation.
A 6 × 6 m floor built from 50 × 50 cm panels needs 12 × 12 = 144 panels, before perimeter edges. Share the clear space and units so the layout can be checked for your project.
Star LED Dance Floor
in focus.
01What creates the 3D star effect?
The floor combines reflected mirror depth with points of RGB light, creating a star pattern beneath the surface. The specification lists 96 built-in effects.
02Can I use the floor outdoors in rain?
The panels are listed as IP67 and the range describes protection for accidental drink spills. The product FAQ explicitly says the floor cannot be used outdoors in rain.
03How much do the panels weigh?
The FAQ lists 11 kg for a 50 cm panel and 14 kg for a 60 cm panel. Flight cases and cartons are separate packing options.
Great events
start here.
Tell us what you have in mind. We’ll help you choose the floor, layout and accessories for your business.
We supply dance floor equipment for purchase.
